R2 Integrated GNSS System

The Trimble® R2 is a compact, durable GNSS receiver that provides an easy-to-use solution for GIS and survey professionals who need to collect highly accurate data in a wide range of geospatial applications. Capable of delivering between submeter and centimeter positioning accuracy in real-time to any mobile device via a wireless Bluetooth® connection, the R2 receiver gives you total flexibility to choose a solution based on the accuracy and GNSS performance level that suits your application, letting you work the way you want.   More Info.

GNSS Type

Post processed (Real Time Optional)

UHF Radio Tx/Rx

Rx Option

Tracking technology

Flood light

RTX

Yes

Cellular

No

WiFi

Yes

Bluetooth

Yes

Antenna

Integrated

Web Interface

Yes

Integrated Survey

Option

GPS

Yes

Glonass

Option

Galileo

Option

BeiDou (Compass)

Option

SBAS

Yes

Battery

Removable

Field solution

Trimble Access - Terraflex

Controller

Slate, TSC3, TCU, Tablette,TSC7

Dimensions

140 mm x 114 mm

Weight

1,08 kg
